Suncoast 68RFE Bonded Valve Body Plate 2011-On



68RFE Bonded Valve Body Plate, 5 Check Ball Design 2011-ON



The 68RFE valve body plate can be used in both stock applications and increased line pressure applications.



Stock applications:



• Overlay the stock separator plate over the new plate and drill 2 holes 7/16″ dia. in the passage way as directed in the supplied instruction sheet.



Heavy Duty applications:



• In order to use this option the customer MUST have aftermarket transmission tuning software that is programmed to command higher than stock pressures. Without the tuning software, this modification will not provide ANY additional line pressure increase. We do not suggest this being done UNLESS you have transmission tuning. Sonnax line pressure boosters are NOT transmission tuning and will NOT work with this modification. If you have a line pressure booster use the stock application option. Drill a 1/8″ dia. hole into the lower valve body casting all the way thru as shown in the supplied instruction sheet.

2023 Ram 2500
2023 Ram 3500
2023 Ram 4500
2023 Ram 5500
2022 Ram 2500
2022 Ram 3500
2022 Ram 4500
2022 Ram 5500
2021 Ram 2500
2021 Ram 3500
2021 Ram 4500
2021 Ram 5500
2020 Ram 2500
2020 Ram 3500
2020 Ram 4500
2020 Ram 5500
2019 Ram 2500
2019 Ram 3500
2019 Ram 4500
2019 Ram 5500
2018 Ram 2500
2018 Ram 3500
2018 Ram 4500
2018 Ram 5500
2017 Ram 2500
2017 Ram 3500
2017 Ram 4500
2017 Ram 5500
2016 Ram 2500
2016 Ram 3500
2016 Ram 4500
2016 Ram 5500
2015 Ram 2500
2015 Ram 3500
2015 Ram 4500
2015 Ram 5500
2014 Ram 2500
2014 Ram 3500
2014 Ram 4500
2014 Ram 5500
2013 Ram 2500
2013 Ram 3500
2013 Ram 4500
2013 Ram 5500
2012 Ram 2500
2012 Ram 3500
2012 Ram 4500
2012 Ram 5500
2011 Ram 2500
2011 Ram 3500
2011 Ram 4500
2011 Ram 5500

SKU: 29995L5

GTIN:

Manufacture Name: Suncoast Performance

Shipping Weight: 3 lb

Shipping Length: 12 in

Shipping Width: 12 in

Shipping Height: 12 in

EO Number:

Cross Reference #
